Product features:

1. A configuration of helix blades was chosen to achieve the required depth and capacity.

2. May be deployed in places with restricted or difficult access

3. Quick installation

4. Installation doesn't produce waste

5. Installation without vibration (unlike driven piles)

6. Concrete can be poured right away after installing the piles.

7. Optional hot-dip galvanizing is offered to further combat corrosion.

8. It is more affordable than other deep foundation options.

9. To get an estimate for new construction helical piles, call or email us.

10. Promotes the stabilization of soil

spiral piles large supplier, superior product quality.
Complete models and specifications,
①High load performance.
②Sturdy and durable.
③Even galvanized.
④Good resistance to settlement.

Product Specifications

Product Benefits

1.Bar Material: Round Corner 5mm Radius, 40Cr or 45# Steel

2.The material for Helix Plates complies with ASTM A36 hot rolled plate.

3. 3/8" and 1/2" inch helices are offered in thickness.

4. Rock cut with a 45-degree angle and all leading edges of helix honed.

5.Corrosion protection for hot-dipped zinc coating to comply with ASTM A153 standard

6. A superior conventional extra-high-strength helical screw pile made of solid steel

7. A welded connector for increased sturdiness. eliminates the damage to the shaft caused by the faulty coupling operation.

In order to replace the conventional cement foundation, HELICAL PILES are primarily used as a new foundation system. It has been extensively used in the foundation of temporary venues, warehouses, schools, and other independent buildings, signal signage foundations, municipal facilities, transportation facilities, power tower foundations, solar photovoltaic support systems, wooden houses, villas, bus shelters, street lamps, and billboards.
